SMA to SMA Adapters Standard Polarity

Check out our new RF calculators & conversion tools...

SMA Male to SMA Female Radius Right Angle Adapter, Functional Up to 26.5 GHz

Product ID: PE91222
SMA Male to SMA Female Radius Right Angle Adapter, Functional Up to 26.5 GHz


Image Views:  SMA Male to SMA Female Radius Right Angle Adapter, Functional Up to 26.5 GHz high resolution
Zoomalternate image
View 2


Click for:PE91222 Datasheet
Click for:PE91222 RoHS Cert
Click for:PE91222 REACH Cert
Available Quantity: 1,852
Pricing Table
QUANTITYPRICE
1-24$73.65
25-49$68.49
50-99$63.34
100-249$58.92
250+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series 1SMA
Connector Gender 1Male
Connector Polarity 1Standard
Connector Impedance 150 Ohm
Connector Series 2SMA
Connector Gender 2Female
Connector Polarity 2Standard
Connector Impedance 250 Ohm
Frequency, MinDC
Frequency, Max26.5 GHz
Adapter Body StyleRadius Right Angle
Connector Mount Method 1None
Connector Body Material 1Passivated Stainless Steel
Connector Mount Method 2None


SMA Male to SMA Female Radius Right Angle Adapter, Functional Up to 26.5 GHz

SMA adapter PE91222 is one of over 40,000 available RF, microwave and millimeter wave components from Pasternack. Our SMA to SMA adapter is a in-series coaxial adapter design. This 50 Ohm SMA adapter is precision manufactured to RF components industry specifications and has a maximum frequency of 26.5 GHz.

SMA male to SMA female adapter is one of the many RF components that ship same day as they are ordered. PE91222 male SMA to female SMA adapter has a radius right angle body. This Pasternack radius right angle SMA coax adapter is a 90 degree swept elbow adapter.

Our male SMA to female SMA adapter PE91222 is shipped from Pasternack's ISO 9001:2008 facility the same day as purchased. This functional up to 26.5 GHz SMA to SMA radio frequency adapter is part of over 40,000 RF, microwave and millimeter wave products that ship the same day worldwide, including custom cable assemblies.
