Low Power SPDT Terminated Electromechanical Relay Switches (<10 Watts)

Check out our new RF calculators & conversion tools...

SPDT 0.03 dB Low Insertion Loss Repeatability Relay Latching Switch, Terminated, DC to 20 GHz, 1W, 24V, Indicators, Self Cut Off, SMA

Product ID: PE71S6337
SPDT 0.03 dB Low Insertion Loss Repeatability Relay Latching Switch, Terminated, DC to 20 GHz, 1W, 24V, Indicators, Self Cut Off, SMA


Image Views:  SPDT 0.03 dB Low Insertion Loss Repeatability Relay Latching Switch, Terminated, DC to 20 GHz, 1W, 24V, Indicators, Self Cut Off, SMA high resolution
Zoomalternate image
View 2


Click for:PE71S6337 Datasheet
Click for:PE71S6337 RoHS Cert
Click for:PE71S6337 REACH Cert
Available Quantity: 4
Pricing Table
QUANTITYPRICE
1-1$1,996.97
2-4$1,877.15
5-9$1,777.30
10+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
Connector SeriesSMA
Connector GenderFemale
Switch DesignSPDT
Minimum FrequencyDC
Maximum Frequency20 GHz
Impedance50 Ohm
Maximum Input Power1 Watts
Maximum Insertion Loss0.5 dB


SPDT 0.03 dB Low Insertion Loss Repeatability Relay Latching Switch, Terminated, DC to 20 GHz, 1W, 24V, Indicators, Self Cut Off, SMA

PE71S6337 electromechanical RF relay switch from Pasternack is a SPDT design. Our SPDT electromechanical RF switch uses SMA connectors at 50 Ohm. This SMA RF relay SPDT switch has a maximum frequency of 20 GHz and maximum power of 1 Watts. The Pasternack radio frequency SPDT SMA electro-mechanical relay switch is rated at a control voltage of 24 Volts, indicator voltage and switching speed of 15ms.

SMA SPDT electro mechanical RF relay switch features Indicators, Self Cut Off with an isolation minimum of dB. SPDT electromechanical relay radio frequency switch PE71S6337 is part of over 40,000 RF, microwave and millimeter wave components available from Pasternack. Our SPDT SMA coaxial RF relay electromechanical switch can ship worldwide the same day that it is bought as with our other available RF parts.
