SSMB Jack Straight Connectors

Check out our new RF calculators & conversion tools...

SSMB Jack Bulkhead Connector Crimp/Solder Attachment For RG174, RG179, RG316, RG188, .126 inch D Hole

Product ID: PE4336
SSMB Jack Bulkhead Connector Crimp/Solder Attachment For RG174, RG179, RG316, RG188, .126 inch D Hole


Image Views:  SSMB Jack Bulkhead Connector Crimp/Solder Attachment For RG174, RG179, RG316, RG188, .126 inch D Hole high resolution
Zoomalternate image
View 2


Click for:PE4336 Datasheet
Available Quantity: 1,154
Pricing Table
QUANTITYPRICE
1-24$39.34
25-49$37.37
50-99$35.41
100-249$33.83
250+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
PolarityStandard
Connector SeriesSSMB
Connector GenderJack
Impedance50 Ohm
Body StyleStraight
Attachment MethodCrimp/Solder
Mount MethodBulkhead


SSMB Jack Bulkhead Connector Crimp/Solder Attachment For RG174, RG179, RG316, RG188, .126 inch D Hole

PE4336 SSMB jack bulkhead coaxial connector has an interface type of .100 inch, RG316, RG174, RG188, LMR-100, LMR-100A, LMR-100A-FR, PE-C100, PE-B100 and a 50 Ohm impedance. Pasternack SSMB jack bulkhead connector uses shield/contact crimp/solder as an attachment method.

The Pasternack SSMB jack bulkhead coaxial connector has a ptfe dielectric type. The Pasternack SSMB coaxial connector has a brass body with gold plating. This SSMB jack bulkhead coaxial RF connector is RoHS and REACH compliant.

This Pasternack jack SSMB bulkhead connector will ship the same day as purchased. Our bulkhead SSMB jack connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom SSMB connector cable assemblies that will ship the same day as well.

*LMR™ is a Trademark of Times Microwave
