WR159 4.90 GHz to 7.05 GHz Standard Gain Horns

Check out our new RF calculators & conversion tools...

WR-159 Waveguide Standard Gain Horn Antenna Operating From 4.9 GHz to 7.05 GHz With a Nominal 20 dBi Gain With CMR-159 Flange

Product ID: PE9860-20
WR-159 Waveguide Standard Gain Horn Antenna Operating From 4.9 GHz to 7.05 GHz With a Nominal 20 dBi Gain With CMR-159 Flange


Image Views:  WR-159 Waveguide Standard Gain Horn Antenna Operating From 4.9 GHz to 7.05 GHz With a Nominal 20 dBi Gain With CMR-159 Flange high resolution
Zoomalternate image
View 2


Click for:PE9860-20 Datasheet
Click for:PE9860-20 REACH Cert
Available Quantity: 17
Pricing Table
QUANTITYPRICE
1-4$955.96
5-9$889.04
10-24$822.13
25-49$764.77
50+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
Waveguide SizeWR-159
Gain Min20
Flange SizeSquare Cover
Frequency, Min4.9 GHz
Frequency, Max7.05 GHz
Beam Width V16.9
Beam Width H14.3


WR-159 Standard Gain Horn Antenna Operating From 4.9 GHz to 7.05 GHz With a Nominal 20 dB Gain With Square Cover Flange

PE9860-20 WR-159 standard gain horn antenna is also known as a waveguide horn. This WR-159 standard gain horn antenna has a 20 dB nominal gain and a square cover flange. Our 20 dB WR-159 horn antenna has a minimum frequency of 4.9 GHz and a maximum frequency of 7.05 GHz.

WR-159 standard gain horn waveguide antenna PE9860-20 has a vertical beam width of 16.9 and horizontal of 14.3 degrees at 3 dB. This WR-159 standard gain horn antenna with 20 dB is part of over 40,000 RF, microwave and millimeter wave components available from Pasternack. Our WR-159 waveguide horn antenna can ship worldwide the same day as it is purchased as with our other available RF parts.
