WR 28 26.5 GHz to 40.0 GHz Standard Gain Horns

Check out our new RF calculators & conversion tools...

WR-28 Waveguide Standard Gain Horn Antenna Operating From 26.5 GHz to 40 GHz With a Nominal 10 dBi Gain With UG-599/U Square Cover Flange

Product ID: PE9850-10
WR-28 Waveguide Standard Gain Horn Antenna Operating From 26.5 GHz to 40 GHz With a Nominal 10 dBi Gain With UG-599/U Square Cover Flange


Image Views:  WR-28 Waveguide Standard Gain Horn Antenna Operating From 26.5 GHz to 40 GHz With a Nominal 10 dBi Gain With UG-599/U Square Cover Flange high resolution
Zoomalternate image
View 2


Click for:PE9850-10 Datasheet
Click for:PE9850-10 RoHS Cert
Click for:PE9850-10 REACH Cert
Available Quantity: 50
Pricing Table
QUANTITYPRICE
1-4$801.61
5-9$745.50
10-24$689.38
25-49$641.29
50+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
Waveguide SizeWR-28
Gain Min10
Flange SizeSquare Cover
Frequency, Min26.5 GHz
Frequency, Max40 GHz
Beam Width V54.4
Beam Width H54.2


WR-28 Standard Gain Horn Antenna Operating From 26.5 GHz to 40 GHz With a Nominal 10 dB Gain With Square Cover Flange

PE9850-10 WR-28 standard gain horn antenna is also known as a waveguide horn. This WR-28 standard gain horn antenna has a 10 dB nominal gain and a square cover flange. Our 10 dB WR-28 horn antenna has a minimum frequency of 26.5 GHz and a maximum frequency of 40 GHz.

WR-28 standard gain horn waveguide antenna PE9850-10 has a vertical beam width of 54.4 and horizontal of 54.2 degrees at 3 dB. This WR-28 standard gain horn antenna with 10 dB is part of over 40,000 RF, microwave and millimeter wave components available from Pasternack. Our WR-28 waveguide horn antenna can ship worldwide the same day as it is purchased as with our other available RF parts.
