TNC Female to SMC Plug Right Angle Cable Assemblies

Check out our new RF calculators & conversion tools...

TNC Female Bulkhead to SMC Plug Right Angle Cable Using RG174 Coax

Product ID: PE36779
TNC Female Bulkhead to SMC Plug Right Angle Cable Using RG174 Coax

Image Views:  TNC Female Bulkhead to SMC Plug Right Angle Cable Using RG174 Coax high resolution
Zoom


Click for:PE36779 Datasheet
Click for:PE36779 RoHS Cert
Please Enter Length to Calculate Price
Standard Lengths
12 in.24 in.36 in.48 in.60 in.
Custom Length
SHIPS SAME DAY
Length:
*Lengths are rounded up to the nearest quarter of inch or centimeter respectively. For precise lengths, please call
866-727-8376.
Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series 1TNC
Connector Gender 1Female
Connector Polarity 1Standard
Connector Angle 1Straight
Connector Mount Method 1Bulkhead
Connector Impedance 150
Connector Series 2SMC
Connector Gender 2Plug
Connector Polarity 2Standard
Connector Angle 2Right Angle
Connector Mount Method 2None
Connector Impedance 250
RF Cable Part NumberRG174A/U
RF Cable TypeRG174
RF Cable Impedance50


TNC Female Bulkhead to SMC Plug Right Angle Cable Using RG174 Coax

PE36779 is a TNC female bulkhead to SMC plug right angle cable using RG174 coax. This Pasternack TNC female bulkhead to SMC plug right angle cable assembly uses a 50 Ohm TNC for connector 1 and a 50 Ohm SMC for connector 2. TNC to SMC right angle coaxial cable assembly uses 90 degree right angle coax cable connector.

Our female TNC bulkhead to plug SMC right angle cable assembly uses a flexible cable type that is 50 Ohm. Pasternack PE36779 TNC female bulkhead to SMC plug right angle cable assembly is constructed with RG174 coax and the maximum VSWR is 1.4:1.
