TRB Jack Bulkhead to TRB Jack Bulkhead Cable Using 78 Ohm PE-30-02001 Coax

Name: TRB Jack Bulkhead to TRB Jack Bulkhead Cable Using 78 Ohm PE-30-02001 Coax
Brand: Pasternack
SKU: PE3W20297
Availability: OutOfStock

Product ID: PE3W20297

Length

Custom Length

* Lengths are rounded to the nearest quarter inch or centimeter. For precise lengths, please call 866-727-8376.

* All cable assembly length tolerance are as provided on the datasheet. If not provided, cable length tolerances are within the IPC standards (2022-24) as shown here.

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series 1	TRB
Connector Gender 1	Jack
Connector Polarity 1	Standard
Connector Angle 1	Straight
Connector Mount Method 1	Bulkhead
Connector Impedance 1	78 Ohm
Connector Series 2	TRB
Connector Gender 2	Jack
Connector Polarity 2	Standard
Connector Angle 2	Straight
Connector Mount Method 2	Bulkhead
Connector Impedance 2	78 Ohm
RF Cable Part Number	PE-30-02001
RF Cable Type	0.242 78 Ohm Twinax
RF Cable Impedance	78 Ohm

Description

Click on the below images to access KitBOM product pages:


PE410-06579-210	PE-30-02001	PE410-06579-210

TRB Jack Bulkhead to TRB Jack Bulkhead Cable Using 78 Ohm PE-30-02001 Coax

PE3W20297 is a TRB jack bulkhead to TRB jack bulkhead cable using 0.242 78 Ohm Twinax coax. This Pasternack TRB jack bulkhead to TRB jack bulkhead cable assembly uses a 78 Ohm TRB for connector 1 and a 78 Ohm TRB for connector 2.

Our jack TRB bulkhead to jack TRB bulkhead cable assembly uses a flexible cable type that is 78 Ohm. Pasternack PE3W20297 TRB jack bulkhead to TRB jack bulkhead cable assembly is constructed with 0.242 78 Ohm Twinax coax.
