10-32 Male to 1.0/2.3 Jack Bulkhead Cable Using LMR-100 Coax

Name: 10-32 Male to 1.0/2.3 Jack Bulkhead Cable Using LMR-100 Coax
Brand: Pasternack
SKU: PE3W00022/HS
Availability: OutOfStock

Product ID: PE3W00022/HS

Length

Custom Length

* Lengths are rounded to the nearest quarter inch or centimeter. For precise lengths, please call 866-727-8376.

* All cable assembly length tolerance are as provided on the datasheet. If not provided, cable length tolerances are within the IPC standards (2022-24) as shown here.

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series 1	10-32
Connector Gender 1	Male
Connector Polarity 1	Standard
Connector Angle 1	Straight
Connector Mount Method 1	None
Connector Impedance 1	50 Ohm
Connector Series 2	1.0/2.3
Connector Gender 2	Jack
Connector Polarity 2	Standard
Connector Angle 2	Straight
Connector Mount Method 2	Bulkhead
Connector Impedance 2	50 Ohm
RF Cable Part Number	LMR-100A-PVC
RF Cable Type	LMR-100A
RF Cable Impedance	50 Ohm

Description

Click on the below images to access KitBOM product pages:


PE44351	LMR-100A-PVC	PE44254	KitBOM Datasheet

10-32 Male to 1.0/2.3 Jack Bulkhead Cable Using LM

PE3W00022/HS is a 10-32 male to 1.0/2.3 jack bulkhead cable using LMR-100A coax. This Pasternack 10-32 male to 1.0/2.3 jack bulkhead cable assembly uses a 50 Ohm 10-32 for connector 1 and a 50 Ohm 1.0/2.3 for connector 2.

Our male 10-32 to jack 1.0/2.3 bulkhead cable assembly uses a flexible cable type that is 50 Ohm. Pasternack PE3W00022/HS 10-32 male to 1.0/2.3 jack bulkhead cable assembly is constructed with LMR-100A coax.

* LMR™ is a trademark of Times Microwave Systems.
