F 75 Ohm Step Attenuators

Check out our new RF calculators & conversion tools...

0 to 71 dB Toggle Step Attenuator, 75 Ohm F Female to 75 Ohm F Female Rated to 1 Watt From 0.3 MHz to 1,000 MHz

Product ID: PE70A1008
0 to 71 dB Toggle Step Attenuator, 75 Ohm F Female to 75 Ohm F Female Rated to 1 Watt From 0.3 MHz to 1,000 MHz


Image Views:  0 to 71 dB Toggle Step Attenuator, 75 Ohm F Female to 75 Ohm F Female Rated to 1 Watt From 0.3 MHz to 1,000 MHz high resolution
Zoomalternate image
View 2


Click for:PE70A1008 Datasheet
Click for:PE70A1008 RoHS Cert
Click for:PE70A1008 REACH Cert
Available Quantity: 23
Pricing Table
QUANTITYPRICE
1-1$754.56
2-4$724.38
5-9$694.20
10+Call

Add to cart
Quantity:

All Prices are in US Dollars and do not include duties
Key Specifications (Click on Data Sheet Above for Additional Details).
DesignStep
Maximum Frequency1,000 MHz
Impedance75 Ohm
Power Maximum1 Watt
VSWR Maximum1.37:1
Connector Series 1F
Connector Gender 1Female
Connector Series 2F
Connector Gender 2Female
Minimum Attenuation0 dB


0 to 71 dB Toggle Step Attenuator, 75 Ohm F Female to 75 Ohm F Female Rated to 1 Watt From 0.3 MHz to 1,000 MHz

PE70A1008 is a stepped attenuator from Pasternack. Our type F attenuator is a RF step attenuator design. This 75 Ohm manual step attenuator is precision manufactured to RF and microwave industry specifications.

The Pasternack coaxial step attenuator has a female gender for connector 1 and a type F female for connector 2. PE70A1008 steped attenuator has a minimum attenuation of 0 dB and a maximum attenuation of 71 dB with 0dB step sizes. Our RF step attenuator has frequency range of 0.3 MHz to 1,000 MHz and a maximum VSWR of 1.37. This adjustable BNC attenuator is rated to 1 at the stated attenuation.

Our stepped attenuator PE70A1008 is shipped from Pasternack's ISO 9001:2008 facility the same day as purchased. This BNC attenuator is part of over 40,000 RF, microwave and millimeter wave products that ship the same day worldwide, including custom cable assemblies.
