Flexible RG219 Coax Cable Single Shielded with Green PVC With Armor Jacket
Product ID:
RG219/U
Key Specifications
Key Specifications (Click on Data Sheet Above for Additional Details). |
Generic Name | RG219 |
Flex Type | Flexible |
Impedance | 50 Ohm |
Dielectric Type | PE |
Jacket Diameter | 0.945 in |
Jacket Material | PVC With Armor |
No. of Shields | 1 |
Attenuation at 1 Ghz. | 3.8 dB |
Power, Max at 1 Ghz. | 560 Watts |
Frequency, Max | 5 GHz |
Max Operating Temperature | 80 deg C |
Center Conductor Type | Solid |
Inner Conductor, Number of Strands | 1 |
Coax Type | Coax |
Description
Flexible RG219 Coax Cable Single Shielded with Green PVC With Armor Jacket
RG219/U part number from Pasternack is a RG219 coax cable that is flexible. Pasternack RG219 flexible coax cable is 50 Ohm and has a PE dielectric. Our RG219 coax is constructed with a 0.945 jacket made of PVC With Armor. RG219 coax has a shield count of 1 and the maximum frequency for this Pasternack cable is 5 GHz. RG219 coax cable has an attenuation at 1 GHz of 3.8 dB and a maximum power of 560 watts at 1 GHz.
Pasternack RG219 coax cables are part of over 40,000 RF, microwave and millimeter wave components. RG219 cables and our other RF parts are available for same day shipping worldwide. Custom RF cable assemblies using RG219 or other coax can be built and shipped same day as well.
