WR-15 Waveguide Horn Antenna Operating From 50 GHz to 75 GHz With a Nominal 20 dBi Gain With UG-385/U Round Cover Flange

Product ID: PE9881-20
WR-15 Waveguide Horn Antenna Operating From 50 GHz to 75 GHz With a Nominal 20 dBi Gain With UG-385/U Round Cover Flange


Image Views:  WR-15 Waveguide Horn Antenna Operating From 50 GHz to 75 GHz With a Nominal 20 dBi Gain With UG-385/U Round Cover Flange high resolution
Zoomalternate image
View 2


Click for:PE9881-20 Datasheet
Click for:PE9881-20 RoHS Cert
DISCONTINUED PRODUCT
Replaced By: PE9881A-20

Key Specifications (Click on Data Sheet Above for Additional Details).
Waveguide SizeWR-15
Flange SizeUG-385/U
Direction TypeDirectional
Frequency, Min50 GHz
Frequency, Max75 GHz
Beam Width, 3dB V20


WR-15 Waveguide Horn Antenna Operating From 50 GHz to 75 GHz With a Nominal 20 dBi Gain With UG-385/U Flange

PE9881-20 WR-15 waveguide horn antenna is also known as a WR-15 horn antenna. This WR-15 waveguide horn antenna has a dB nominal gain and a ug-385/u flange. Our dB WR-15 horn antenna has a minimum frequency of 50 GHz and a maximum frequency of 75 GHz.

WR-15 horn antenna PE9881-20 has a vertical beam width of 20 and horizontal of degrees at 3 dB. This WR-15 waveguide horn antenna with dB is part of over 40,000 RF, microwave and millimeter wave components available from Pasternack. Our WR-15 horn antenna can ship worldwide the same day as it is purchased as with our other available RF parts.
