N Male to SMC Jack Cable Using RG316-DS Coax
Product ID:
PE3W00003
* Lengths are rounded to the nearest quarter inch or centimeter. For precise lengths, please call 866-727-8376.
* Lengths are rounded to the nearest quarter inch or centimeter. For precise lengths, please call 866-727-8376.
Key Specifications
| Key Specifications (Click on Data Sheet Above for Additional Details). |
| Connector Series 1 | N |
| Connector Gender 1 | Male |
| Connector Polarity 1 | Standard |
| Connector Angle 1 | Straight |
| Connector Mount Method 1 | None |
| Connector Impedance 1 | 50 Ohm |
| Connector Series 2 | SMC |
| Connector Gender 2 | Jack |
| Connector Polarity 2 | Standard |
| Connector Angle 2 | Straight |
| Connector Mount Method 2 | None |
| Connector Impedance 2 | 50 Ohm |
| RF Cable Part Number | RG316-DS |
| RF Cable Type | RG316-DS |
| RF Cable Impedance | 50 Ohm |
Description
Click on the below images to access KitBOM product pages:
 |  |  |  |
|---|
| PE45167 | RG316-DS | PE45156 | KitBOM Datasheet |
|---|
N Male to SMC Jack Cable Using RG316-DS Coax
PE3W00003 is a N male to SMC jack cable using RG316-DS coax. This Pasternack N male to SMC jack cable assembly uses a 50 Ohm N for connector 1 and a 50 Ohm SMC for connector 2.
Our male N to jack SMC cable assembly uses a flexible cable type that is 50 Ohm. Pasternack PE3W00003 N male to SMC jack cable assembly is constructed with RG316-DS coax.
