Pasternack Debuts New Lines of Waveguide Bends Up to 90 GHz across 12 Frequency Bands

Waveguide Bends from Pasternack Available in WR-12 to WR-137 Now In-Stock

Waveguide Bends Up to 90 GHz across 12 Frequency Bands

Irvine, CA - Pasternack, a leading provider of RF, microwave and millimeter wave products, debuts brand new lines of waveguide bends operating from 5.85 to 90 GHz across 12 frequency bands (from C band to W band). These waveguide bends are commonly used in applications such as instrumentation, test benches, high efficiency RF, microwave and mm-wave transmissions, SATCOM, MILCOM, radar and telecom.

In waveguide systems that require a signal to turn or bend 90 degrees, precision waveguide bends are used as to not degrade the transmission signal. Pasternack’s broad portfolio of in-stock and ready-to-ship waveguide bends boast low loss and VSWR as low as 1.08:1 and are available in both E-plane and H-plane configurations. These 90 degree waveguide bends are constructed using gold plated, oxygen free hard copper (OFHC) or painted copper alloy depending on the model. The bends are also offered with either a UG-style flange per the military standard or a CPR-style flange.

In this portfolio, there are currently 30 unique models of waveguide bends offered from stock at Pasternack. Sizes range from WR-137 (5.85 GHz) to WR-12 (90 GHz). Most models are RoHS compliant.

“To complement our rapidly expanding portfolio of waveguide components, we are pleased to offer a full range of waveguide bends over twelve bands from C to W band in both H and E plane configurations,” says Mark Blackwood, Passive Components Product Manager at Pasternack. “These new waveguide products are a welcome addition to our large and growing waveguide line designed to meet the urgent requirements of our customers.”

The new waveguide bends from Pasternack are in-stock and ready to ship now. For more detailed information, please visit https://www.pasternack.com/pages/RF-Microwave-and-Millimeter-Wave-Products/waveguide-bends.html. Pasternack can be contacted at +1-949-261-1920.

###

About Pasternack

A leader in RF products since 1972, Pasternack is an ISO 9001:2008 certified manufacturer and supplier offering the industry’s largest selection of active and passive RF, microwave and millimeter wave products available for same-day shipping.
