Threshold Detectors Covering Microwave and Millimeter Wave Frequencies from 2 to 40 GHz New from Pasternack

Pasternack Releases Threshold Detectors Used for Analyzing Radar Performance & Leveling Pulsed Signal Sources

Threshold Detectors from Pasternack

Irvine, CA - Pasternack, a leading manufacturer and supplier of RF, microwave and millimeter wave products, introduces a new line of coaxial threshold detectors designed for microwave and millimeter wave applications from 2 to 40 GHz. These threshold detectors are commonly used for analyzing radar performance, leveling pulsed signal sources, AM noise measurements, system monitoring and pulsed RF measurements in ultra-broadband applications.

Pasternack’s latest release of threshold detectors consists of 3 unique models covering broadband frequency bands from 2 to 40 GHz. Designs incorporate gain stages for higher dynamic range that cover input power levels ranging from -45 dBm to 0 dBm with a typical threshold variation over frequency of ± 0.5 dB. One model supports a fixed threshold while the other 2 models support an adjustable threshold setting. All models feature a TTL compatible video output response which is “1” when the RF signal is above the threshold setting and “0” when it’s below the threshold setting.

Additional features of the new threshold detectors from Pasternack include rugged construction utilizing compact packages with field replaceable SMA or 2.92mm connectors. These models are designed to meet MIL-STD-202F environmental conditions for temperature cycle, humidity, shock, vibration and altitude. The threshold detectors also boast extremely fast response times ranging from 45 to 100 nanoseconds, maximum input power handling ranging from +10 to +17 dBm, and have an operating temperature range of -55 to +85 degrees Celsius.

“These adjustable threshold detectors have the features and broadband performance that are particularly useful for designers who need to analyze critical signal response characteristics,” explains Tim Galla, Active Components Product Manager at Pasternack.

The new threshold detectors from Pasternack are in-stock and ready to ship now. For detailed information on these products, please visit http://www.pasternack.com/pages/RF-Microwave-and-Millimeter-Wave-Products/threshold-detectors.html. Pasternack can be contacted at +1-949-261-1920.

###

About Pasternack

A leader in RF products since 1972, Pasternack is an ISO 9001:2008 certified manufacturer and supplier offering the industry’s largest selection of active and passive RF, microwave and millimeter wave products available for same-day shipping.
