8 7 6 5 4 3 2 1
NOTICE OF PROPRIETARY RIGHTS THIS DOCUMENT CONTAINS CONFIDENTIAL DATA, INCLUDING TRADE SECRETS, PROPRIETARY TO TIMES VER Description ECN Name Date
MICROWAVE SYSTEMS. DISCLOSURE OF THIS DATA IS EXPRESSLY CONDITIONED UPON YOUR ASSENT THAT ITS USE IS LIMITED TO USE WITHIN A Release for production N/A Joslen 2017/3/22
YOUR COMPANY ONLY. ANY OTHER USE IS STRICTLY PROHIBITED WITHOUT THE PRIOR WRITTEN CONSENT OF TIMES MICROWAVE SYSTEMS.

F F

body contact pin insulator Ferrule

BNC plug
E E
9,50

12,70

D heat shrink tube D
30,50

12,70 [0'500"]

I. MATERIALS & FINISHES II. ELECTRICAL PROPERTIES
C C
Components Materials Finishes Thk. (µ") Impedance (Ω): 50 38,10
Body Brass Albaloy 100 Frequency Range (GHz): DC to 4 GHz [1'500"]
Center Cont. Brass Gold 50 Working Voltage (V): ≥1000
Ferrule Brass Albaloy 100 Insulation Resistance (MΩ): ≥10000
Coupling Nut Brass Albaloy 100 VSWR: ≤1.30
Insulator PTFE N/A N/A Insertion Loss(dB, f/GHz): -0.1x √f
Gasket Silicone Red N/A

B B
III. ENVIRONMENT PROPERTIES IV. MECHANICAL PROPERTIES
Temperature Range: -40°c - +125°c Center Conductor: Solder
Thermal Shock: MIL-STD 202G, Meth.107, Cond.B Outer Conductor.: Crimp
Vibration: MIL-STD 202G, Meth.204, Cond.B Coupling Nut Torque (N.m): Bayonet Lock
Shock: MIL-STD 202G, Meth.213, Cond I Cable-Connector Retention Force (N): 500 Standard: IEC-60169-8
Climatic Class: IEC 60068 55/155/56 Durability (cycles): 500 UNLESS OTHERWISE SPECIFIED DFTM Joslen
(2002/95/EC)RoHS: Compliant ALL DIMENSIONS ARE IN mm DATE 2017/3/22 TIMESMICROWAVE SYSTEMS
MACHINED SURFACES FINISH 1.6 RMS MAX. An Amphenol Company
REMOVE ALL BURRS 0.15X45˚ MAX. BREAK CHKD
A V. TOOLING MACHINE CORNERS 0.15X45˚ D MAX. FILLET Joslen TC-240-BM-X A
BNC Male (plug) Solder Pin
Stripping Tool: 3192-152 R. TOLERANCES ON DECIMALS DATE 2017/3/22 Connector No Braid Trim for LMR-
.X ±0.3 .XX ±0.15
Crimping Tool: 3190-667/CT-240/200/100 ANGLES ±2° FRACTIONS ± N/A APPD Tony 240 Cable

Scale: 4:1 Size: A3 CODE 68999 DATE 2017/3/22 S H T 1/1 3190-6380 R E V A
IDENT
8 7 6 5 4 3 2 1
