MCX Jack Connector Solder Attachment End Launch PCB

RF Connectors Technical Data Sheet PE44661

Material Specifications
Description Material Plating
Contact Brass/Beryllium Copper Gold
10µ in. minimum

Insulation Teflon
Body Brass Gold
3µ in. minimum

.

Environmental Specifications
Temperature
Operating Range -55 to +155 deg C

Compliance Certifications (see product page for current document)

Plotted and Other Data
Notes:

Assembly Instruction

MCX Jack Connector Solder Attachment End Launch PCB from Pasternack Enterprises has same day shipment for domestic
and International orders. Our RF, microwave and millimeter wave products maintain a 99.4% availability and are part of the
broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: MCX Jack Connector Solder Attachment End Launch PCB PE44661

URL: https://www.pasternack.com/mcx-jack-standard-surface-mount-end-launch-connector-pe44661-p.aspx
