N Female Connector Crimp/Solder Attachment 4 Hole
Flange Mount for RG316, RG174, LMR-100, IP67 Rated

RF Connectors Technical Data Sheet PE45133

Material Specifications
Description Material Plating
Contact Brass Gold

Insulation Teflon
Body Brass Nickel
100µ in. minimum

.

Environmental Specifications
Temperature
Operating Range -20 to +80 deg C

Compliance Certifications (see product page for current document)

Plotted and Other Data
Notes:

Assembly Instruction

N Female Connector Crimp/Solder Attachment 4 Hole Flange Mount for RG316, RG174, LMR-100, IP67 Rated from Pasternack
Enterprises has same day shipment for domestic and International orders. Our RF, microwave and millimeter wave products
maintain a 99.4% availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: N Female Connector Crimp/Solder Attachment 4 Hole Flange Mount for RG316, RG174, LMR-
100, IP67 Rated PE45133

URL: https://www.pasternack.com/n-female-rg316-rg174-lmr-100-connector-pe45133-p.aspx

PE45133 REV 1.2 2
