Page 2 - Waveguides Product Selection Guide

Broad Selection of Ready-to-Ship Waveguides

Pasternack offers the industry’s largest selection of both passive and active waveguide building block components that cover
microwave and millimeter wave bands up to 220 GHz. This vast selection consists of 27 different categories with over thousands
of models that include low noise and power amplifiers, detectors, bandpass filters, pin diode and electromechanical relay switches,
converter mixers, antennas, attenuators, phase shifters, oscillators, couplers, gain horns, magic tees, terminations, transitions,
adapters, twists, bends, sections, flexible waveguides, and assembly accessories. All models are available in-stock for immediate
shipment. System designs that utilize integrated waveguide components and interconnects result in a completely shielded signal path
with excellent isolation that results in optimum signal processing performance. Another benefit is that extremely high peak power levels
can be transmitted with very low losses. Applications include point to point radio links, test and measurement, industrial and front end
radars, sensors, and wireless communication.

All models can be viewed online at www.pasternack.com with comprehensive datasheets that include typical performance graphs,
detailed CAD drawings and real-time pricing and inventory.

Waveguide Low Noise Amplifiers ...................................2 Specialty Waveguide Antennas ..............................32
Waveguide Power Amplifiers ..........................................2 Waveguide Antenna Accessories .................................32
Waveguide Converters/Mixers ........................................2 Waveguide to Coax Adapters .................................32
Waveguide Frequency Multipliers...................................3 Corner Reflectors ....................................................44
Waveguide Detectors .......................................................4 Flexible Waveguide ........................................................45
Waveguide Electromechanical Relay Switches .............4 Waveguide Bandpass Filters .........................................50

Waveguide PIN Diode Switches ......................................9 Waveguide Bends ...........................................................51
Waveguide Gunn Oscillators ...........................................9 Waveguide Bulkhead Adapters .....................................54
Waveguide Direct Read Attenuators .............................10 Waveguide Circulators ...................................................55
Waveguide Fixed Attenuators .......................................10 Waveguide Couplers ......................................................55
Waveguide Variable Attenuators ...................................12 Waveguide Isolators .......................................................70
Waveguide Antennas .....................................................13 Waveguide Magic Tee .....................................................70
Waveguide Antennas with Coax Adapters ............13 Waveguide Orthomode Transducers ............................71
Standard Gain Horns ..............................................18 Waveguide Phase Shifters .............................................71

Conical Gain Horns .................................................25 Waveguide Polarizers.....................................................72
Wide Angle Scalar Feed Horns ..............................28 Waveguide Rotary Joints ...............................................72
Lens ..........................................................................29 Waveguide Sections .......................................................73
Omni Directional .....................................................30 Waveguide Terminations ...............................................80
Probe ........................................................................30 Waveguide Transitions...................................................84
Sector .......................................................................31 Waveguide Twists ...........................................................85
Dual Polarized .........................................................31 Waveguide Accessories .................................................88

1 Available for Same-Day Shipping
