N Female to BNC Female Adapter
RF Adapters Technical Data Sheet PE9206
Typical Performance Data
dB Return Loss
0
-10
-20
-30
-40
-50
-60
S11 S22
-70
0.00 GHz 0.30 0.60 0.90 1.20 1.50 1.80 2.10 2.40 2.70 3.00
dB Insertion Loss
0.00
-0.20
-0.40
-0.60
-0.80
-1.00
0.00GHz 0.30 0.60 0.90 1.20 1.50 1.80 2.10 2.40 2.70 3.00
