UHF Male to UHF Female Right Angle Adapter

RF Adapters Technical Data Sheet PE9209

Material Specifications

Connector 1 Connector 2
Description Material Plating Material Plating
Type UHF Male UHF Female
Contact Brass Gold Brass Gold
30 µInch 30 µInch
Insulation PTFE PTFE
Outer Conductor Brass Nickel
100 µInch
Body Brass Nickel
100 µInch
Coupling Nut Brass Nickel
100 µInch
. .

Environmental Specifications
Temperature
Operating Range -55 to +85 deg C
.

Compliance Certifications (see product page for current document)

Plotted and Other Data
Notes:

UHF Male to UHF Female Right Angle Adapter from Pasternack Enterprises has same day shipment for domestic and
International orders. Our RF, microwave and millimeter wave products maintain a 99.4% availability and are part of the
broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: UHF Male to UHF Female Right Angle Adapter PE9209

URL: https://www.pasternack.com/uhf-male-uhf-female-right-angle-adapter-pe9209-p.aspx

-
