75 Ohm BNC Female to BNC Female 4 Hole Flange Adapter
RF Adapters Technical Data Sheet PE9367
.
Description Connector 1 Connector 2
Type BNC Female BNC Female
Polarity Standard Standard
.
Material Specifications
Connector 1 Connector 2
Description Material Plating Material Plating
Type BNC Female BNC Female
Contact Brass Gold Brass Gold
Insulation PTFE PTFE
Outer Conductor Brass Nickel Brass Nickel
. .
Environmental Specifications
Temperature
Operating Range -65 to +165 deg C
.
Compliance Certifications (see product page for current document)
Plotted and Other Data
Notes:
Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: 75 Ohm BNC Female to BNC Female 4 Hole Flange Adapter PE9367
PE9367 REV 1.1 2
