PE38772 CAD Drawing
MCX Plug Right Angle to SMA Female Bulkhead Cable Using RG316-DS Coax

7361

.448 11.38

SMA FEMALE BULKHEAD MOUNTING HOLE SIZE A

5/16 HEX

.125 3.18 MAX. PANEL .235 5.97 MIN .250 6.35 MIN 2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME. SCALE N/A
HEATSHRINK SLEEVE 1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL.

3. DIMENSIONS ARE IN INCHES [mm]. 121317

NOTES: CAD FILE

LENGTH MEASURED FROM CONTACT TO FLANGE RG316-DS COAX CABLE DWG TITLE PE38772 CAGE CODE 53919

Pasternack does not make Phone: (949) 261-1920 | Fax: (949) 261-7451
R
THE ENGINEER'S RF SOURCE Pasternack Enterprises, Inc. P.O. Box 16759 | Irvine | CA | 92623 Website: www.pasternack.com | E-Mail: sales@pasternack.com

HEATSHRINK SLEEVE

.XXX ±0.005
R.A MCX MALE STANDARD TOLERANCES *STANDARD TOLERANCES APPLY ONLY TO DIMENSIONS IN INCHES -
.XX ±0.01
.X ±0.2
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.

PE38772 REV 1.0 4
