PE44397 CAD Drawing
N Female Bulkhead Mount Connector Solder Attachment
Thru Hole PCB, .640 inch DD Hole

.400 10.16 7361

SIZE A

.400 10.16 SCALE N/A

1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL. 2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME.

.062 1.57 TYP 3. DIMENSIONS ARE IN INCHES [mm]. 08/23/18

.125 3.18 TYP .400 10.16 TYP PCB MOUNTING HOLE CAD FILE
.125 3.17 TYP NOTES:

.750 19.05 .067 +.005 -.000 0.00

1.70 +0.13
.279 7.09 5X PE44397 CAGE CODE 53919

DWG TITLE
.536 +.005 -.000 13.61 +0.13 0.00 MOUNTING HOLE

.700 17.78 MAX. PANEL

1.975 50.17 .750 [19.05] HEX

R
P.O. Box 16759 | Irvine | CA | 92623
.630 +.005 -.000 0.00
1.290 32.77 16.00 +0.13
Pasternack Enterprises, Inc.
N FEMALE BULKHEAD THE ENGINEER'S RF SOURCE

.531 [13.49] ACROSS FLATS Pasternack does not make Phone: (949) 261-1920 | Fax: (949) 261-7451 Website: www.pasternack.com | E-Mail: sales@pasternack.com

5/8-24 UNEF STANDARD TOLERANCES *STANDARD TOLERANCES APPLY ONLY TO DIMENSIONS IN INCHES
.XXX ±0.005
.XX ±0.01
.X ±0.2

any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation. -

PE44397 REV 1.2 3
