75 Ohm N Male Connector Crimp/Non-Solder
Contact Attachment for LMR-400-75

RF Connectors
Technical Data Sheet EZ-400-NMH-75-X

Material Specifications
Description Material Plating
Contact Brass Gold
50 µ inch minimum

Insulation Teflon
Body Brass Tri-Metal
80 µ inch minimum

Coupling Nut Brass Tri-Metal
80 µ inch minimum
.

Environmental Specifications
Temperature
Operating Range -40 to +125 deg C
Shock MIL-STD 202G, Meth. 213, Cond. I
Vibration MIL-STD 202G, Meth. 204, Cond. B
Thermal Shock MIL-STD 202G, Meth. 107, Cond. B

Compliance Certifications (see product page for current document)
Plotted and Other Data
Notes:

75 Ohm N Male Connector Crimp/Non-Solder Contact Attachment for LMR-400-75 from Pasternack Enterprises has same
day shipment for domestic and International orders. Our RF, microwave and millimeter wave products maintain a 99.4%
availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: 75 Ohm N Male Connector Crimp/Non-Solder Contact Attachment for LMR-400-75 EZ-400-NMH-
75-X

URL: https://www.pasternack.com/n-male-lmr-400-75-connector-ez-400-nmh-75-x-p.aspx

-
Pasternack does not make
any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.

EZ-400-NMH-75-X REV 1.1 2
