BNC Female Connector Solder Attachment End Launch PCB

RF Connectors Technical Data Sheet PE44616

Mating Cycles 500 Cycles

Material Specifications
Description Material Plating
Contact Brass Gold
Insulation PTFE

Body Brass Nickel
.

Environmental Specifications
Temperature
Operating Range -65 to +165 deg C

Compliance Certifications (see product page for current document)

Plotted and Other Data
Notes:

BNC Female Connector Solder Attachment End Launch PCB from Pasternack Enterprises has same day shipment for
domestic and International orders. Our RF, microwave and millimeter wave products maintain a 99% availability and are part
of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: BNC Female Connector Solder Attachment End Launch PCB PE44616

URL: https://www.pasternack.com/bnc-female-standard-surface-mount-end-launch-connector-pe44616-p.aspx
