N Female Field Replaceable Connector
4 Hole Flange Mount Slotted Contact Terminal,
1.0 inch Sq. Flange Watt Meter Connector

RF Connectors Technical Data Sheet PE44722

Material Specifications
Description Material Plating
Contact Silver
QQ-S-365

Insulation PTFE
Body Brass Nickel
QQ-N-290

.

Environmental Specifications
Temperature
Operating Range -65 to +165 deg C

Compliance Certifications (see product page for current document)

Plotted and Other Data
Notes:

N Female Field Replaceable Connector 4 Hole Flange Mount Slotted Contact Terminal, 1.0 inch Sq. Flange Watt Meter
Connector from Pasternack Enterprises has same day shipment for domestic and International orders. Our RF, microwave
and millimeter wave products maintain a 99% availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: N Female Field Replaceable Connector 4 Hole Flange Mount Slotted Contact Terminal, 1.0 inch
Sq. Flange Watt Meter Connector PE44722

URL: https://www.pasternack.com/n-female-standard-slotted-contact-terminal-connector-pe44722-p.aspx

PE44722 REV 1.1 2
