PE4508 CAD Drawing
75 Ohm N Male Connector Crimp/Solder Attachment for RG6,
Compatible With Inner Conductor Smaller Than 0.030 Inch

7361

SIZE A

.374 9.50 2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME. SCALE N/A

.343 8.70 1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL.
.260 6.60

.197 5.00 3. DIMENSIONS ARE IN INCHES [mm]. 111317

.500 12.70 FERRULE

CAD FILE
NOTES:

1.11±.020 28.3±0.5 .83±.02 21.0±0.5 5/8-24 UNEF PE4508 CAGE CODE 53919

.031 0.80
.083 2.10 DWG TITLE

.827 21.00 R
Pasternack does not make Phone: (949) 261-1920 | Fax: (949) 261-7451
.705 17.91 CONTACT
THE ENGINEER'S RF SOURCE Pasternack Enterprises, Inc. P.O. Box 16759 | Irvine | CA | 92623 Website: www.pasternack.com | E-Mail: sales@pasternack.com

STANDARD TOLERANCES *STANDARD TOLERANCES APPLY ONLY TO DIMENSIONS IN INCHES -

.XXX ±0.005
.XX ±0.01
.X ±0.2

any representation or warranty regarding the suitability of the part described herein for any particular purpose, and Pasternack does not assume any liability arising out of the use of any part or documentation.

PE4508 REV 1.2 5
