Page 91 - Waveguides Product Selection Guide

Waveguide Accessories-Shims
PE P/N Description
PEW10FS2 WR-10 Waveguide Shim, UG-Cover Round flange, 2mm Brass

PEW12FS2 WR-12 Waveguide Shim, UG-Cover Round flange, 2mm Brass

PEW15FS2 WR-15 Waveguide Shim, UG-Cover Round flange, 2mm Brass

PEW19FS3 WR-19 Waveguide Shim, UG-Cover Round flange, 3mm Brass

PEW22FS3 WR-22 Waveguide Shim, UG-Cover Round flange, 3mm Brass

PEW28FS3 WR-28 Waveguide Shim, UG-Cover Square flange, 3mm Brass

PEW34FS4 WR-34 Waveguide Shim, UG-Cover Square flange, 4mm Brass

PEW42FS4 WR-42 Waveguide Shim, UG-Cover Square flange, 4mm Brass

PEW62FS5 WR-62 Waveguide Shim, UG-Cover Square flange, 5mm Brass

PEW75FS5 WR-75 Waveguide Shim, UG-Cover Square flange, 5mm Brass

PEW90FS5 WR-90 Waveguide Shim, UG-Cover Square flange, 5mm Brass

PEW112FS5 WR-112 Waveguide Shim, UG-Cover Square flange, 5mm Brass

PEW137FS7 WR-137 Waveguide Shim, CPR-137F flange, 7mm Brass

PEW159FS7 WR-159 Waveguide Shim, CPR-159F flange, 7mm Aluminum

PEW187FS7 WR-187 Waveguide Shim, CPR-187F flange, 7mm Aluminum

PEW284FS8 WR-284 Waveguide Shim, CPR-284F flange, 8mm Aluminum
