SMA Circulators

Check out our new RF calculators & conversion tools...

Product Filters

Hide Filters

Frequency Band

Max Power (Watts)

Isolation (dB)



Page:1 2  Move Next
High Power Circulator With 18 dB Isolation From 1 GHz to 2 GHz, 50 Watts And SMA Female
High Power Circulator With 18 dB Isolation From 1 GHz to 2 GHz, 50 Watts And SMA Female
Product ID: PE83CR1000
High Power Circulator With 20 dB Isolation From 1.7 GHz to 2.2 GHz, 50 Watts And SMA Female
High Power Circulator With 20 dB Isolation From 1.7 GHz to 2.2 GHz, 50 Watts And SMA Female
Product ID: PE83CR1002
High Power Circulator With 20 dB Isolation From 2 GHz to 4 GHz, 50 Watts And SMA Female
High Power Circulator With 20 dB Isolation From 2 GHz to 4 GHz, 50 Watts And SMA Female
Product ID: PE83CR1004
High Power Circulator With 18 dB Isolation From 4 GHz to 8 GHz, 50 Watts And SMA Female
High Power Circulator With 18 dB Isolation From 4 GHz to 8 GHz, 50 Watts And SMA Female
Product ID: PE83CR1006
High Power Circulator With 20 dB Isolation From 7 GHz to 12.4 GHz, 50 Watts And SMA Female
High Power Circulator With 20 dB Isolation From 7 GHz to 12.4 GHz, 50 Watts And SMA Female
Product ID: PE83CR1008
High Power Circulator With 16 dB Isolation From 8 GHz to 18 GHz, 50 Watts And SMA Female
High Power Circulator With 16 dB Isolation From 8 GHz to 18 GHz, 50 Watts And SMA Female
Product ID: PE83CR1010
High Power Circulator With 20 dB Isolation From 11 GHz to 18 GHz, 50 Watts And SMA Female
High Power Circulator With 20 dB Isolation From 11 GHz to 18 GHz, 50 Watts And SMA Female
Product ID: PE83CR1011
High Power Circulator With 17 dB Isolation From 18 GHz to 26.5 GHz, 50 Watts And SMA Female
High Power Circulator With 17 dB Isolation From 18 GHz to 26.5 GHz, 50 Watts And SMA Female
Product ID: PE83CR1012
Dual Junction Circulator With 36 dB Isolation From 1 GHz to 2 GHz, 10 Watts And SMA Female
Dual Junction Circulator With 36 dB Isolation From 1 GHz to 2 GHz, 10 Watts And SMA Female
Product ID: PE83CR1013
Dual Junction Circulator With 40 dB Isolation From 1.7 GHz to 2.2 GHz, 10 Watts And SMA Female
Dual Junction Circulator With 40 dB Isolation From 1.7 GHz to 2.2 GHz, 10 Watts And SMA Female
Product ID: PE83CR1015
Dual Junction Circulator With 40 dB Isolation From 2 GHz to 4 GHz, 10 Watts And SMA Female
Dual Junction Circulator With 40 dB Isolation From 2 GHz to 4 GHz, 10 Watts And SMA Female
Product ID: PE83CR1017
Dual Junction Circulator With 36 dB Isolation From 4 GHz to 8 GHz, 10 Watts And SMA Female
Dual Junction Circulator With 36 dB Isolation From 4 GHz to 8 GHz, 10 Watts And SMA Female
Product ID: PE83CR1019
Dual Junction Circulator With 40 dB Isolation From 7 GHz to 12.4 GHz, 5 Watts And SMA Female
Dual Junction Circulator With 40 dB Isolation From 7 GHz to 12.4 GHz, 5 Watts And SMA Female
Product ID: PE83CR1021
Dual Junction Circulator With 32 dB Isolation From 8 GHz to 18 GHz, 5 Watts And SMA Female
Dual Junction Circulator With 32 dB Isolation From 8 GHz to 18 GHz, 5 Watts And SMA Female
Product ID: PE83CR1023
Dual Junction Circulator With 40 dB Isolation From 11 GHz to 18 GHz, 5 Watts And SMA Female
Dual Junction Circulator With 40 dB Isolation From 11 GHz to 18 GHz, 5 Watts And SMA Female
Product ID: PE83CR1024
Circulator With 18 dB Isolation From 1 GHz to 2 GHz, 1 Watt And SMA Female
Circulator With 18 dB Isolation From 1 GHz to 2 GHz, 1 Watt And SMA Female
Product ID: PE8400
Circulator With 18 dB Isolation From 2 GHz to 4 GHz, 1 Watt And SMA Female
Circulator With 18 dB Isolation From 2 GHz to 4 GHz, 1 Watt And SMA Female
Product ID: PE8401
Circulator With 18 dB Isolation From 4 GHz to 8 GHz, 10 Watts And SMA Female
Circulator With 18 dB Isolation From 4 GHz to 8 GHz, 10 Watts And SMA Female
Product ID: PE8402
Circulator With 18 dB Isolation From 7 GHz to 12.4 GHz, 10 Watts And SMA Female
Circulator With 18 dB Isolation From 7 GHz to 12.4 GHz, 10 Watts And SMA Female
Product ID: PE8403
Circulator With 16 dB Isolation From 8 GHz to 18 GHz, 10 Watts And SMA Female
Circulator With 16 dB Isolation From 8 GHz to 18 GHz, 10 Watts And SMA Female
Product ID: PE8404
Page:1 2  Move Next

SMA Circulators

Pasternack SMA circulators are passive 3-port microwave devices which control the signal direction and flow inside of an RF circuit. RF circulators are also unidirectional, but circulate the flow of energy from each port to its clockwise adjacent port. Like isolators, circulators are made of ferrite materials and magnets which determine the direction that the entering signal will flow. These RF circulators have minimum isolation ratings between 16 dB and 20 dB.


50 Ohm SMA circulators have frequency capabilities ranging from 1 GHz to 26.5 GHz depending on type and style and have very low insertion loss. Pasternack Enterprises’ SMA circulators have a power of 10 Watts and maximum VSWR of 1.45:1. Many of our RF/microwave SMA circulators are RoHS and REACH compliant.


The ISO 9001:2008 registered Pasternack facility ships SMA circulators from stock the same day you order them. Pasternack Enterprises offers the broadest and deepest inventory of RF and microwave components available. Expert technical support and friendly customer service personnel are always here to assist you. (sales@pasternack.com, techsupport@pasternack.com, 866-727-8376 US and Canada or +1-949-261-1920 International).
