Diplexers

Diplexers

Pasternack's diplexers, available for immediate delivery, are purposefully crafted to accommodate an extensive range of end-user applications, encompassing UHF/VHF, cable TV, FM, and data transmission. Our diplexers, precisely engineered with a 75ohm impedance and F-type connectorized designs, provide outstanding performance across a variety of low-pass and high-pass frequency bands.

Achieve Concurrent Signal Transmission and Reception Across Diverse Frequency Bands

Availability

Pasternack’s diplexers are in-stock and ready to ship with no minimum order quantities.

Exceptional Performance

These diplexers are meticulously designed with a 75ohm impedance and F-type connectorized configurations, delivering superior performance across a wide range of low-pass and high-pass frequency bands.

Numerous Applications

The pass bands of these diplexers span a broad array of application frequency ranges, including MSO applications, FM bands, UHF/VHF bands, and satellite TV bands.

Diplexer Features

Low Insertion Loss

The minimal insertion loss of these diplexers enhances signal quality, boosts energy efficiency, and ensures peak system performance.

Simple and Secure Connections

The F-type connectors incorporated in these diplexers enable swift and easy setup, and ensure a secure and firm connection.

Low VSWR

Impressive VSWR performance ensuring effective power transmission, improved system efficiency, and extended lifespan of your equipment.

High Out-of-Band Rejections

The superior out-of-band rejection capability of these diplexers guarantees passage for only the intended frequencies, resulting in more distinct and purer signal transmission and reception.
