PE70A8000 CAD Drawing
6 Bit Relay Controlled Programmable Attenuator, 63 dB Up
to 1,000 MHz, 1 dB Steps, +12V, SMA Female

CN_0992

3.500 88.9 O.C. SIZE A

1.125 28.6 1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL. 2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME. SCALE N/A

4-40 x .250 DP (4-PLACES) 3. DIMENSIONS ARE IN INCHES [mm]. 040517 CAD FILE

2-56 BIN. HD. .44 11.2 TYP. TYP. NOTES:

TYP.
.13 3.3

CAGE CODE 53919
C L 1.13 28.7 PE70A8000
DWG TITLE

.38 9.7

.44 11.2 TYP.

.63 16.0

.04 1.0
R
SMA FEMALE (2-PLACES) THE ENGINEER'S RF SOURCE

Pasternack Enterprises, Inc. P.O. Box 16759 | Irvine | CA | 92623 Phone: (949) 261-1920 | Fax: (949) 261-7451 Website: www.pasternack.com | E-Mail: sales@pasternack.com
C L 1.63 41.4

STANDARD TOLERANCES *STANDARD TOLERANCES APPLY ONLY TO DIMENSIONS IN INCHES
4.00 101.6

.X ±0.2 .XX ±0.1 .XXX ±0.05

PE70A8000 REV 1.0 6
