31.5 dB With 6 Bit Programmable TTL Controlled Attenuator,
SMA Female to SMA Female, 0.5 dB Steps Up to 13 GHz

TECHNICAL DATA SHEET PE70A4000

Performance Data

Normalized Attenuation (Only Major
States are Shown)

0

-5

-10
NORMALIZED ATTENUATION (dB) -20
-15

-25

-30
-35
0 3 6 9 12 15
FREQUENCY (GHz)

Relative Phase vs. Frequency (Only Major States
are Shown)

100
90
80
70
60 31.5 dB
RELATIVE PHASE (deg) 40 16 dB 0.5 - 4 dB
50

30
20
10
0 8 dB
-10
0 3 6 9 12 15
FREQUENCY (GHz)

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: 31.5 dB With 6 Bit Programmable TTL Controlled Attenuator, SMA Female to SMA Female,
0.5 dB Steps Up to 13 GHz PE70A4000

PE70A4000 REV 1.0 4
