Page 26 - Waveguides Product Selection Guide

Standard Gain Horns Continued
PE P/N Waveguide Type RF Frequency Range (GHz) Gain (dB) Flange Type ECCN
PEWAN284-15 WR-284 2.6 - 3.95 15 CMR-284 EAR99

PE9863B-20 WR-284 2.6 - 3.95 20 CMR-284 EAR99

PE9863B-20-U WR-284 2.6 - 3.95 20 Round Cover UG-584/U EAR99

PEWAN284-20 WR-284 2.6 - 3.95 20 CMR-284 EAR99

PE9864B-10 WR-430 1.7 - 2.6 10 CPR-430F EAR99

PEWAN430-10 WR-430 1.7 - 2.6 10 CPR-430F EAR99

PE9864B-15 WR-430 1.7 - 2.6 15 CPR-430F EAR99

PEWAN430-15 WR-430 1.7 - 2.6 15 CPR-430F EAR99

PE9864B-20 WR-430 1.7 - 2.6 20 CPR-430F EAR99

Conical Gain Horns
PE P/N Waveguide Type RF Frequency Range (GHz) Gain (dB) Flange Type ECCN
PEWAN1065 WR-5 140 - 220 10 Round Cover UG-387/U EAR99

PEWAN1066 WR-5 140 - 220 15 Round Cover UG-387/U EAR99

PEWAN1067 WR-5 140 - 220 20 Round Cover UG-387/U EAR99

PEWAN1068 WR-5 140 - 220 25 Round Cover UG-387/U EAR99

PEWAN1061 WR-6 100 - 112 10 Round Cover UG-387/U-Mod EAR99
