Omni Directional
PE P/N Waveguide Type RF Frequency Range (GHz) Gain (dB) Flange Type ECCN
PEWAN1135 WR-10 90 - 100 0 Round Cover UG-387/U-Mod EAR99
PEWAN1136 WR-10 90 - 100 6.5 Square Cover UG-387/U-Mod EAR99
PEWAN1089 WR-10 89 - 99 2 Round Cover UG-387/U EAR99
PEWAN1088 WR-12 75 - 79 2 Round Cover UG-387/U EAR99
PEWAN1134 WR-12 71 - 86 2 Round Cover UG-387/U EAR99
PEWAN1087 WR-15 58 - 62 3.5 Round Cover UG-385/U EAR99
PEWAN1133 WR-28 26.5 - 40 7.5 Square Cover UG-599/U EAR99
Probe Waveguide Antennas
PE P/N Waveguide Type RF Frequency Range (GHz) Gain (dB) Flange Type ECCN
PEWAN1124 WR-6 110 - 170 6.5 Round Cover UG-387/U-Mod EAR99
PEWAN1125 WR-8 90 - 140 6.5 Round Cover UG-387/U-Mod EAR99
PEWAN1126 WR-10 75 - 110 6.5 Round Cover UG-387/U-Mod EAR99
PEWAN1127 WR-12 60 - 90 6.5 Round Cover UG-387/U EAR99
PEWAN1128 WR-15 50 - 75 6.5 Round Cover UG-385/U EAR99
PEWAN1129 WR-19 40 - 60 6.5 Round Cover UG-383/U-Mod EAR99
PEWAN1130 WR-22 33 - 50 6.5 Round Cover UG-383/U EAR99
