Dual Polarized Waveguide Antennas Continued
PE P/N Waveguide Type RF Frequency Range (GHz) Gain (dB) Flange Type ECCN
PEWAN1140 WR-22 33 - 50 15 Square Cover UG-383/U EAR99
PEWAN1142 WR-28 24 - 42 10 Square Choke UG-599/U EAR99
PEWAN1112 WR-28 24 - 42 15 UG-599/U EAR99
PEWAN1111 WR-28 24 - 40 15 UG-599/U EAR99
Specialty Waveguide Antennas
PE P/N Waveguide Type RF Frequency Range (GHz) Gain (dB) Flange Type ECCN
PE9887-11 Broadband 1 - 18 11 dBi SMA Connectors EAR99
PE9888-11 Broadband 1 - 18 11 dBi N Connectors EAR99
PE9881-42 WR-15 50 - 75 42 Round Cover 5A991
PE9881A-20 WR-15 50 - 75 20 Round Cover EAR99
PEW15A001 WR-15 50 - 75 2 dBi Round Cover EAR99
PE9881-34 WR-15 56.5 - 67 34 dBi Round Cover 5A991
Waveguide to Coax Adapters
PE P/N Waveguide Type RF Frequency Maximum Flange Type Connector Body Style ECCN
Range (GHz) VSWR
PE-W10CA003 WR-10 75 - 110 1.32:1 Round Cover UG-387/U-Mod 1.0mm Female Right Angle EAR99
PE-W10CA004 WR-10 75 - 110 1.33:1 Round Cover UG-387/U-Mod 1.0mm Male Right Angle EAR99
