Page 32 - Waveguides Product Selection Guide
P. 32
Probe Waveguide Antennas Continued
PE P/N Waveguide Type RF Frequency Range (GHz) Gain (dB) Flange Type ECCN
PEWAN1131 WR-28 26.5 - 40 6.5 Square Cover UG-599/U EAR99
PEWAN1132 WR-34 22 - 33 6.5 Square Cover UG-1530/U EAR99
Sector Waveguide Antennas
PE P/N Waveguide Type RF Frequency Range (GHz) Gain (dB) Flange Type ECCN
PEWAN1144 WR-28 30 - 40 0 Square Cover UG-599/U-Mod EAR99
PEWAN1143 WR-28 27.5 - 29.5 6 Square Cover UG-599/U EAR99
Dual Polarized Waveguide Antennas
PE P/N Waveguide Type RF Frequency Range (GHz) Gain (dB) Flange Type ECCN
PEWAN1121 WR-10 75 - 110 13 UG-387/U-Mod EAR99
PEWAN1137 WR-10 75 - 110 15 Square Cover UG-387/U-Mod EAR99
PEWAN1141 WR-10 75 - 110 20 Square Cover UG-387/U-Mod EAR99
PEWAN1119 WR-12 60 - 90 13 UG-387/U EAR99
PEWAN1138 WR-12 60 - 90 15 Square Cover UG-387/U EAR99
PEWAN1139 WR-12 50 - 75 15 Square Cover UG-385/U EAR99
PEWAN1117 WR-15 50 - 75 13 UG-385/U-Mod EAR99
PEWAN1116 WR-19 40 - 60 13 UG-383/U-Mod EAR99
31 Available for Same-Day Shipping
