Waveguide Antennas with Coax Adapters Continued
PE P/N Waveguide Type RF Frequency Range Gain (dB) Flange Type Connector ECCN
(GHz)
PE9854B/NF-20 WR-62 12.4 - 18 20 WR-62 N Female EAR99

PE9854B/SF-20 WR-62 12.4 - 18 20 WR-62 SMA Female EAR99

PE9855B/NF-10 WR-75 10 - 15 10 WR-75 N Female EAR99

PE9855B/SF-10 WR-75 10 - 15 10 WR-75 SMA Female EAR99

PE9855B/NF-15 WR-75 10 - 15 15 WR-75 N Female EAR99

PE9855B/SF-15 WR-75 10 - 15 15 WR-75 SMA Female EAR99

PE9855B/NF-20 WR-75 10 - 15 20 WR-75 N Female EAR99

PE9855B/SF-20 WR-75 10 - 15 20 WR-75 SMA Female EAR99

PE9856B/NF-10 WR-90 8.2 - 12.4 10 WR-90 N Female EAR99

PE9856B/SF-10 WR-90 8.2 - 12.4 10 WR-90 SMA Female EAR99

PE9856B/NF-15 WR-90 8.2 - 12.4 15 WR-90 N Female EAR99

PE9856B/SF-15 WR-90 8.2 - 12.4 15 WR-90 SMA Female EAR99

PE9856B/NF-20 WR-90 8.2 - 12.4 20 WR-90 N Female EAR99

PE9856B/SF-20 WR-90 8.2 - 12.4 20 WR-90 SMA Female EAR99

PE9857B/NF-10 WR-102 7 - 11 10 WR-102 N Female EAR99

PE9857B/SF-10 WR-102 7 - 11 10 WR-102 SMA Female EAR99
