Page 17 - Waveguides Product Selection Guide

Waveguide Antennas with Coax Adapters Continued
PE P/N Waveguide Type RF Frequency Range Gain (dB) Flange Type Connector ECCN
(GHz)
PE9860B/NF-10 WR-159 4.9 - 7.05 10 WR-159 N Female EAR99

PE9860B/SF-10 WR-159 4.9 - 7.05 10 WR-159 SMA Female EAR99

PE9860B/NF-15 WR-159 4.9 - 7.05 15 WR-159 N Female EAR99

PE9860B/SF-15 WR-159 4.9 - 7.05 15 WR-159 SMA Female EAR99

PE9860B/NF-20 WR-159 4.9 - 7.05 20 WR-159 N Female EAR99

PE9860B/SF-20 WR-159 4.9 - 7.05 20 WR-159 SMA Female EAR99

PE9861B/NF-10 WR-187 3.95 - 5.85 10 WR-187 N Female EAR99

PE9861B/SF-10 WR-187 3.95 - 5.85 10 WR-187 SMA Female EAR99

PE9861B/NF-15 WR-187 3.95 - 5.85 15 WR-187 N Female EAR99

PE9861B/SF-15 WR-187 3.95 - 5.85 15 WR-187 SMA Female EAR99

PE9861B/NF-20 WR-187 3.95 - 5.85 20 WR-187 N Female EAR99

PE9861B/SF-20 WR-187 3.95 - 5.85 20 WR-187 SMA Female EAR99

PE9862B/NF-10 WR-229 3.3 - 4.9 10 WR-229 N Female EAR99

PE9862B/SF-10 WR-229 3.3 - 4.9 10 WR-229 SMA Female EAR99

PE9862B/NF-15 WR-229 3.3 - 4.9 15 WR-229 N Female EAR99

PE9862B/SF-15 WR-229 3.3 - 4.9 15 WR-229 SMA Female EAR99
