Waveguide to Coax Adapters Continued
PE P/N Waveguide Type RF Frequency Maximum Flange Type Connector Body Style ECCN
Range (GHz) VSWR
PE9870 WR-112 7.05 - 10 1.3:1 Square Type N Female End Launch EAR99
PE9884 WR-112 7.05 - 10 1.3:1 Square Type SMA Female Right Angle EAR99
PE9865 WR-112 7.05 - 10 1.4:1 Square Type SMA Female End Launch EAR99
PEWCA1049 WR-137 5.85 - 8.2 1.25:1 CMR-137 N Female Right Angle EAR99
PEWCA1048 WR-137 5.85 - 8.2 1.25:1 CMR-137 SMA Female Right Angle EAR99
PEWCA1017 WR-137 5.85 - 8.2 1.25:1 CPR-137G N Female Right Angle EAR99
PEWCA1051 WR-137 5.85 - 8.2 1.25:1 CPR-137G N Female Right Angle EAR99
PEWCA1015 WR-137 5.85 - 8.2 1.25:1 CPR-137G SMA Female Right Angle EAR99
PEWCA1050 WR-137 5.85 - 8.2 1.25:1 CPR-137G SMA Female Right Angle EAR99
PEWCA1087 WR-137 5.38 - 8.17 1.25:1 PDR70 N Female Right Angle EAR99
PEWCA1016 WR-137 5.85 - 8.2 1.25:1 Round Cover UG-344/U N Female Right Angle EAR99
PEWCA1047 WR-137 5.85 - 8.2 1.25:1 Round Cover UG-441/U N Female Right Angle EAR99
PEWCA1014 WR-137 5.85 - 8.2 1.25:1 Round Cover UG-344/U SMA Female Right Angle EAR99
PEWCA1046 WR-137 5.85 - 8.2 1.25:1 Round Cover UG-441/U SMA Female Right Angle EAR99
PEWCA1086 WR-137 5.38 - 8.17 1.25:1 UDR70 N Female Right Angle EAR99
PEWCA1088 WR-137 5.38 - 8.17 1.25:1 UDR70 SMA Female Right Angle EAR99
