Waveguide Bends up to 110 GHz

Waveguide Bend Series

Pasternack’s lines of waveguide bends operate from 5.85 to 90 GHz across 12 frequency bands. In waveguide systems that require a signal to turn or bend 90 degrees, precision waveguide bend components are used as to not degrade the transmission signal. Pasternack’s broad portfolio of in-stock and ready-to-ship waveguide bends boast low loss and VSWR as low as 1.08:1 and are available in both E-plane and H-plane configurations.

These 90 degree waveguide bend are constructed using gold plated, oxygen free hard copper (OFHC) or painted copper alloy depending on the model. The bends are also offered with either a UG-style flange per the military standard or a CPR-style flange. The Pasternack waveguide bend product line is commonly used in high power applications such as instrumentation, test benches, high efficiency RF, microwave and mm-wave transmissions, SATCOM, MILCOM, radar and telecom.

Most Pasternack models of bends are RoHS compliant. Like the other over 40,000 RF, microwave and millimeter wave components, waveguide bends are in-stock. Not only are they in stock, the waveguide bend series ships the same day as purchased.
