Gain Blocks

Pasternack's broad Line of

All in stock and ready for same-day shipping

▼ Click on a part number below for product details

PE P/N

Amplifier
Type

Frequency
Band (GHz)

"Gain
(dB)"

"Gain Variation
+/-(dB)"

"P1dB
(dBm)"

"P1dB
(Watts)"

"Psat
(dBm)"

"NF
(dB)"

"IP3
(dBm)"

"DC Power
(Volts/mA)"

"Mechanical Dimensions
L(in) X W(in) X H(in)"

Connector
Type

ECCN

PE1517

Gain Block

0.05 - 1.0

22

0.75

12

0.015

12/100

2.36 x 2.36 x 0.75

SMA

EAR99


PE1518

Gain Block

0.05 - 2.0

22

1

12

0.015

12/100

2.36 x 2.36 x 0.75

SMA

EAR99


PE1525

Gain Block

0.02 - 2.5

19

15

0.031

12/120

1.38 x 1.18 x 0.49

SMA

EAR99


PE1513

Gain Block

0.01 - 3.0

14

9

0.008

12/50

1.38 x 1.18 x 0.49

SMA

EAR99


PE1514

Gain Block

0.01 - 3.0

10

9

0.008

12/40

1.38 x 1.18 x 0.49

SMA

EAR99


PE1527

Gain Block

0.01 - 3.0

12

9.7

0.009

12/40

1.38 x 1.18 x 0.50

SMA

EAR99


PE15A8000

Gain Block

0.05 - 4.0

26

1

23

0.2

5

35

12/120

2.08 x 1.08 x 0.50

SMA

EAR99


PE15A8001

Gain Block

0.01 - 6.0

15

1

14

0.0

5

26

12/50

1.2 x 0.85 x 0.18

SMA

EAR99


PE1516

Gain Block

0.1 - 3.0

18

14

0.025

12/120

1.38 x 1.18 x 0.49

SMA

EAR99


PE1519

Gain Block

1 - 4

26

0.5

15

0.031

12/100

2.36 x 2.36 x 0.75

SMA

EAR99


PE1520

Gain Block

2 - 4

26

0.5

15

0.031

12/100

2.36 x 2.36 x 0.75

SMA

EAR99


PE1524

Gain Block

2 - 18

23

1

13

0.020

12/120

1.083 x 1.093 x 0.382

SMA

EAR99


PE1523

Gain Block

6 - 18

22

1

13

0.020

12/120

1.083 x 1.093 x 0.382

SMA

EAR99
